Commissioning and Use of Turbine Flow Meters

I. Pre-Installation Preparation

1. Equipment Inspection

Confirm Equipment is in Good Condition: Check the flow meter for external damage and rust, ensure all accessories are complete, and confirm the model and specifications meet design requirements.

Assess Site Conditions: Check the cleanliness, straightness, and support of the pipeline to ensure it meets installation requirements.

Develop a Construction Plan: Based on site conditions and equipment characteristics, develop detailed installation steps, safety measures, and quality control points.

2. Pipeline Preparation

Thoroughly Purge Pipelines: Remove welding slag, rust, dust, and other impurities to prevent damage to turbine blades.

Ensure Sealing: Check that pipeline connections are properly sealed and leak-free.

Prepare Filtration Device: Prepare a filter with an appropriate mesh size (generally 20-60 mesh) based on the medium.

II. Installation Process

1. Installation Requirements

Installation Direction: The flow meter must be installed horizontally with the indicator facing upwards; the fluid flow direction must be consistent with the arrow direction indicated on the flow meter housing.

Straight Pipe Section Requirements:

Upstream Straight Pipe Section: Recommended to be at least 10 times the pipe diameter (10D).

Downstream straight pipe section: It is recommended to have at least 5 times the pipe diameter (5D).

If there are flow-disrupting components such as elbows or valves upstream, the straight pipe section needs to be even longer (e.g., 20D or more).

Avoid stress installation: The pipes at both ends of the flow meter should be coaxial with the flow meter to avoid mechanical stress caused by pipe misalignment.

2. Key Installation Steps

**Filter Installation:** A gas filter (Y-type or T-type) must be installed upstream of the flow meter to prevent particulate matter from entering the meter and damaging the bearings and turbine.

**Deaerator/Dehydrator:** If the gas may contain droplets or oil, a deaerator or dehydrator should be installed upstream.

**Reliable Grounding:** The flow meter should be reliably grounded to prevent static electricity buildup and electromagnetic interference.

**Sealing:** When using flange connections, the sealing gasket must not penetrate deep into the pipe cavity to prevent affecting fluid flow.

III. Commissioning and Calibration

1. Pre-Commissioning Inspection

**Confirm Correct Installation:** Check that the flow meter’s installation direction and straight pipe section meet requirements, and that the connection seal is good.

**Filter Inspection:** Ensure the filter is clean and free of blockages.

**Downstream Valve Confirmation:** Ensure the downstream valve is closed to prevent sudden flow impact.

2. Commissioning Steps

**Slowly Open the Upstream Valve:** Allow gas to slowly enter the pipeline to charge the flow meter. Avoid rapid opening to prevent high-speed airflow from damaging the turbine blades.

Check for leaks: Under low pressure, check the flow meter and all connections for leaks.

Slowly open downstream valves: After confirming there are no leaks, slowly open the downstream valves to gradually build up system pressure and flow.

Operational Monitoring: Observe whether the flow meter’s mechanical counter or electronic display is working properly, and monitor whether the flow rate, pressure, and temperature are within the instrument’s allowable range.

3. Calibration Method

Check Flow Meter Coefficient: Confirm that the coefficient set in the flow meter converter is consistent with the K value marked on the sensor.

Calibrate Zero Point and Full Scale Value:

Place the fluid in a static state and adjust the data display to zero.

Adjust the full scale value by adding a large amount of fluid to the pipeline or using a standard calibration device.

Adjust Sensitivity: Adjust the sensitivity of the turbine flow meter according to the actual measurement conditions to ensure the accuracy of the measurement results.

Calibrate Error Deviation: Compare the actual measured value with the standard value and make adjustments to achieve the calibration purpose.

IV. Operating Procedures

1. Opening and Closing Sequence: Flow sensor without bypass pipe:

First, open the upstream valve of the flow meter to a medium opening.

Then, slowly open the downstream valve.

Run at a low flow rate for a period of time (approximately 10 minutes).

Fully open the upstream valve, then fully open the downstream valve to adjust to the required normal flow rate.

Flow meter with bypass pipe:

First, fully open the bypass valve.

Open the upstream valve to a medium opening.

Slowly open the downstream valve.

1. Reduce the bypass valve opening to allow the instrument to operate at a lower flow rate.

Fully open the upstream valve and fully close the bypass valve (ensuring no leakage).

Adjust the downstream valve opening to the required flow rate.

2. Special Operating Conditions

Low-temperature and high-temperature fluids:

Drain all moisture from the pipeline before starting flow.

Run at a very low flow rate for 15 minutes, then gradually increase to the normal flow rate.

Slowly stop flow to allow the pipeline temperature to gradually approach the ambient temperature.

Prevent water hammer effect:

Open and close the valve as smoothly as possible.

Use a “two-stage opening, two-stage closing” method.

Prevent sudden fluid impact on the impeller.

3. Operation Monitoring

Observe the displayed values: Ensure that the instantaneous flow rate and cumulative flow rate are displayed normally.

Monitor abnormal noise: Pay attention to any abnormal noise (such as metallic friction sound), which may be a sign of bearing damage.

Check pressure changes: When the pipeline pressure is not high, check whether the downstream pressure of the flow meter is greater than Pmin (Pmin = 2ΔP + 1.25Pv).

V. Maintenance and Troubleshooting

Regular Maintenance

Maintenance Cycle: Generally every six months, with calibration performed based on usage conditions (medium cleanliness, operating time) (recommended every 1-2 years).

Filter Cleaning: Regularly clean or replace the upstream filter to ensure it remains unobstructed.

Bearing Wear Inspection: After prolonged use, bearings may wear, requiring factory inspection or replacement.

Storage Requirements: When the flow meter is not in use, the internal liquid should be cleaned, protective sleeves should be added to both ends of the sensor to prevent dust and dirt from entering, and it should be stored in a dry place.

3. Common Faults and Solutions: No Flow Rate Display:

Check for wiring problems, such as a loose or broken signal cable.

Check if the flow meter impeller is tangled or damaged.

Large Flow Rate Fluctuations:

Check for interference sources (such as motors or frequency converters).

Confirm if it is pulsating flow; increase the straight pipe distance between the pump and the flow meter.

Large Display Error:

Check if the flow sensor coefficient K value and other instrument parameters are set correctly.

If possible, perform actual calibration using an electronic scale.

Low Flow Rate Display:

Check if the impeller rotation is obstructed or if the blades are broken.

Remove the flow meter from the pipe and check for tangling or damage.

VI. Important Precautions

**For Clean Gases Only:** Strictly prohibited for use in environments containing large amounts of dust, droplets, or corrosive gases.

**Avoid Over-range Use:** The flow rate must not exceed the instrument’s range; otherwise, it will accelerate wear and may even damage the turbine.

**Prevent Impact from Dry State:** The sensor must not be subjected to impact from high-speed fluid when it is dry.

**Temperature and Pressure Compensation:** For measuring standard state volumetric flow rate (e.g., Nm³/h), temperature and pressure sensors must be used for temperature and pressure compensation.

**Explosion-proof Requirements:** In flammable and explosive environments (e.g., natural gas stations), models meeting explosion-proof standards (e.g., Exd IIB T4) must be selected.

**Practical Recommendations:** In practical applications, it is recommended to regularly evaluate the performance of the turbine flow meter, especially when operating conditions change. For critical measurement points, consider installing an online calibration system to ensure the continuous reliability of measurement data. Operators should receive professional training and be familiar with the equipment characteristics and emergency handling methods. Through standardized commissioning and usage procedures, the measurement accuracy and service life of the turbine flow meter can be significantly improved, providing reliable flow data support for enterprises.
